RS PRO 4 Core Power Cable, 6 mm², 50m, Black PVC Sheath, NYY-J, 1 kV, 600 V

Product Details

RS PRO NYY-J Mains Power Cable

From RS PRO a high-quality NYY-J mains power cable also known as a power control cable with a PVC outer sheath and a nominal voltage rating of 600/1000V. This durable and cost-efficient mains cable is used for the electrical energy supply in fixed wiring installations both indoors and outdoors. The cable can be directly buried under the ground, in brickwork, in concrete as well as submerged under water for a limited period of time.

Cable Construction

This electrical mains power cable consists of cores made up of IEC 60228 class 1 solid copper conductors. Each individual core is surrounded by colour coded PVC (Polyvinyl Chloride) insulation for easy identification of the wires. The cores are then surrounded by a final outer layer of a tough PVC called a sheath or jacket. This power cable also has a filler compound which fills the gaps between the cores and the outer sheath to give the cable a round shape.

Features and Benefits

• Flame retardant to IEC 60332-1 & EN 50265-2-1

• Mechanically tough, durable and resistant to abrasion

• UV and weather resistant

• Lightweight

• Good electrical and insulation properties

• Corrosion resistant and rustproof

• Cost effective due to long cable lifespan

Document

• Technical Datasheets

Specifications
